10 Settings
General
The following flow meter-specific settings can be adjusted for controlling LEDs and alarm output:
 nominal flow rate
 low flow alarm limit
 high flow alarm limit
 alarm filtering
 flow meter shutdown and start-up
The following monitor-specific settings are common for all flow meters in the monitor:
 display units for oil flow and temperature
 oil viscosity grade
 flow meter type
 pre-alarm limit
 alarm mode of Flowline Relay-CAN module (visible only if add-on Flowline Relay-CAN module has been
installed)
 CAN-bus ID-number
Entering the setting mode
Password is a combination of numbers within the range of 000…999. It must be entered before monitor
settings can be changed.
The default password is 000. It can be changed only by SKF Flowline Software (optional).
1 Press SET-key for about 3 seconds, until text "PPP" appears on display.
2 Use the arrow keys to enter the first digit in the password and accept it with the SET key. The next num-
ber field is automatically activated.
3 Select and accept second and third digit as descripted in step 2 above.
4 If the entered password is valid, text "ACC" is displayed and monitor goes into setting mode. If the en-
tered password is not valid, text "Err" is displayed and monitor goes back to measuring mode.
