SKF FL15 - 13 Technical Specifications

FMON10JEN 07.04.2017 Rev. 10J
44 (44)
13 Technical specifications
Table 11 SKF Flowline monitor, technical specifications
Description Value
Operating temperature 0…+65°C (+32…+150°F)
Resettable polymer fuse 750mA
Operating voltage 20…36 VDC
24 VAC (-20%...+5%)
Operating current 150mA max.
Alarm output
Potential free contact
Max load:
30 VDC/1A, 120VAC/1A, resistive load
* Oil viscosity 32 – 1000 cSt, 40°C
Protection classification IP65
Dimensions
226…618 x 106 x 150 mm
(w x d x h)
FL15 oil input connection, threading
FL50 oil input connection, threading
FL100 oil input connection, threading
BSPP G1 (EN ISO 228-1) or NPT 1
BSPP G1 (EN ISO 228-1) or NPT 1
Standard 2 x G1 (EN ISO 228-1) or 2 x NPT 1
Or with connection block 1 x G1 ¼ or 1 x NPT 1 ¼
FL15 oil output connection, threading
FL50 oil output connection, threading
FL100 oil output connection, threading
BSPP G1/2 (EN ISO 228-1) or NPT 1/2
BSPP G1 (EN ISO 228-1) or NPT 1
BSPP G1 ¼ or 1 x NPT 1 ¼ (connection block
standard) OR BSPP 2 x G1 (EN ISO 228-1) or 2 x
NPT 1
Oil flow range FL15 monitor
** Oil flow range, FL50 monitor
** Oil flow range, FL100 monitor
0,1- 15 l/min,
15 – 50 l/min
50 – 100 l/min
Pressure loss over flowmeter
FL15, 150 cSt, 15l/min max ∆P = 1 bar / 14,5 Psi
FL50, 150 cSt, 50 l/min max ∆P = 1 bar / 14,5 Psi
FL100, 150 cSt, 100 l/min max ∆P = 1 bar / 14,5
Psi
Highest allowed input pressure 10 bar /145 Psi
Accuracy *** FL-15: +-5% of reading
FL 50 & FL 100: +-5% of reading
* for low and high flows and viscosities, contact to SKF reseller to ensure flow meter proper operation
** FL50 and FL100 can also be used in the flow range below minimum, 15l/min for FL50 and 50 l/min for
FL100, but measuring accuracy is not sufficient for the low volumes.
*** Operating oil viscosity 100…1000 cSt
