Table 12 Symbols
FLXX-YY-Z-WWW Abbreviation Description
FL: FL SKF Flowline monitor
XX: 15 Flowmeter type, FL15
50 Flowmeter type, FL50
100 Flowmeter type, FL100
YY: 01 Monitor FL50 or FL100 single flowmeter
02 Monitor FL15 with 2 pcs flowmeters
04 Monitor FL15 with 4 pcs flowmeters
06 Monitor FL15 with 6 pcs flowmeters
08 Monitor FL15 with 8 pcs flowmeters
10 Monitor FL15 with 10 pcs flowmeters
Z: R Connections, G-female threads
U Connections, NPT-female threads
WWW: RCM Relay and CAN bus interface module (OPTIONAL)
CAN CAN bus interface module (OPTIONAL)
mA mA-output module (OPTIONAL)
Example:
FL15-06- R
SKF Flowline monitor
Flowmeter type
6 pcs flowmeters
Connections: G- female threads
