Exiting the setting mode
10.3.1 Saving parameters and exiting
Press SET key for approx. 3 seconds until message "END" is displayed. The monitor saves the changed pa-
rameters and goes back to measuring mode.
10.3.2 Exiting without saving parameters
If monitor is in setting mode and the keys have not been used for 2 minutes, the monitor goes back to measur-
ing mode without saving any changes. Message “CAn” (Cancel) is displayed.
If the power is switched off while the monitor is in setting mode, the changes are not saved.
Flow meter-specific settings
In setting mode, all 10 flow meters of FL-15 are selectable on display, even if the monitor
does not have the full number of flow meters. Only one flowmeter can be selected for type
FL-50 and FL100. The nominal flow and alarm limits of the non-existing flow meters must be
zero.
10.4.1 Nominal flow rate
The high alarm limit cannot be set lower than the nominal flow rate. The low alarm limit can-
not be set higher than the nominal flow rate. It may be necessary to adjust the nominal flow
rate first. Refer 9.4.2 Alarm limits
The nominal flow rate is the flow rate specified for the lubrication point.
Nominal flow rate is used to control the operation of the flow meter LEDs. Nominal flow rate refers to the flow
rate level which the middle LED is set to indicate. Refer to section 8.5 and Table 1.
1 Press SET-key to select a flow meter. Flow meter LED blinks to indicate that the flow meter has been se-
lected.
2 Press MODE-key, until signal FLOW is lit.
3 Use arrow keys to set the nominal flow rate.
1 Exit setting mode or adjust other settings.
