Monitor-specific settings
Monitor-specific settings are common parameters for all flow meters in the monitor.
10.5.1 Display units for flow rate and temperature
Flow rate can be displayed in either liters per minute (L/MIN) or pints per minute (PINTS/MIN).
Temperature can be displayed either in degrees Celsius (
C) or degrees Fahrenheit (
F).
1 Press SET-key, until either °C or °F is displayed.
2 Select combination with MODE-key:
°C + L/MIN
°F + L/MIN
°C + PINTS/MIN
°F + PINTS/MIN
A LED is lit to indicate the flow rate unit and the display indicates the temperature unit.
3 Exit setting mode or adjust other settings.
10.5.2 Oil viscosity grade
The oil viscosity grade setting is the ISO VG grade of the oil in +40°C. This value is used with measured tem-
perature for calculating the flow rate accurately.
1 Press SET-key, until text OIL is displayed, toggling with the current set value.
2 Use arrow keys to enter the new viscosity grade.
3 Exit setting mode or adjust other settings.
10.5.3 Flow meter type
1 Press SET-key, until text TYP is displayed, toggling with the current set value.
2 Use arrow keys to change the flow meter type. The numeric value displayed refers to the flow meter type.
"15" refers to type FL15, “50” refers to type FL50 and “100” refers to type FL100
3 Exit setting mode or adjust other settings.
