FMON10JEN 07.04.2017 Rev. 10J
56 (56)
The current outputs are galvanically isolated from the supply voltage of FL monitor.
If isolation is not required, terminals 71 and 72 can be connected to the supply voltage of FL monitor.
In this case the supply voltage of the monitor is limited to 24VDC+-20%.
Table 19 Connections
Terminal
Signal, FL-15
51 ***
4 ...20 mA output, flowmeter 1
52 ***
0
53 4 ...20 mA output, flowmeter 2
54 0
55 4 ...20 mA output, flowmeter 3
56 0
57 4 ...20 mA output, flowmeter 4
58 0
59 4 ...20 mA output, flowmeter 5
60 0
61 4 ...20 mA output, flowmeter 6
62 0
63 4 ...20 mA output, flowmeter 7
64 0
65 4 ...20 mA output, flowmeter 8
66 0
67 4 ...20 mA output, flowmeter 9
68 0
69 4 ...20 mA output, flowmeter 10
70 0
71 Current loop supply 24V +-20%, 200mA max.
72 Current loop supply 0V
*** When using FL 50 or FL 100 signal output 51 and 52 are used.
