14. Spare parts
14
Progressive metering device components – VPG (inch thread) and VPM (metric thread)
Item
Designation
VPG VPM
Order No. Order No.
15 Starter plate for 4/2 and 3/2 directional solenoid valve 44-0711-2265 44-0711-2266
16 4/2 directional solenoid valve, 24 V DC 161-140-050+924
17 Coupler socket according to DIN EN175301-803A 179-990-033
18 Fixing bolt for directional control valve DIN912-M5×45-8.8
19 Sealing ring 508-108 DIN7603-A14×18-AL
20 Plug screw DIN908-R1-4-5.8 DIN908-M14×1.5-5.8
21 2/2 directional solenoid valve for grease, 24 V DC 161-110-031+924
22 Adapter plate 44-1503-2366 44-1503-2366
23 Screws for adapter plate DIN936-M6×16-4.8
24 Inter-screw connection 853-750-024 402-116-351
25 Sealing ring - DIN7603-A14×18-CU
26 2/2 directional solenoid valve for oil, 24 V DC, incl. rectangular connector VPG-VEN+924 VPM-VEN+924
27 Starter plate with flow limiter 24-1883-2272 24-1883-2273
- 105 -
951-230-008-EN
Version 04
