4. Technical data
4.2.4 VPKG progressive metering device with 2/2 directional
solenoid valve for oil, attachment 13
VPKG with 2/2 directional solenoid valve, attachment 13,
Table 13
VPKG progressive metering device
For further technical data, see VPK basic design
Thread connection: Inlet: G1/8"
Ambient temperature range - 15 to + 75 °C
Hydraulic system
Operating pressure max. Oil 150 bar
Lubricant Mineral oils and synthetic oils
Dynamic viscosity 20-1000 mm
2
/s
Electrical system
Directional solenoid valve
(When ordering, please state voltage, type of current, and
frequency)
Valve function 2/2 directional solenoid valve
Type/operation Pusher/solenoid
Basic position De-energized open NO
Voltages 24 V DC
Rated current 1.3 A at 24 V DC
1
)
ON-time 100% ON-time
Protection class IP 65
Electrical connection Plug / DIN 43650
1) Other operating voltage on request
4.2.5 VPKG progressive metering device with 2/2 directional
solenoid valve for grease, attachment 15
VPK with 2/2 directional solenoid valve, attachment 15, Table 14
VPK progressive metering device
For further technical data, see VPK basic design
Thread connection:
Inlet: G1/4"
Ambient temperature range - 25 to + 80 °C
Hydraulic system
Operating pressure max. Grease 300 bar
Lubricant Greases up to NLGI Grade 2
Electrical system
Directional solenoid valve
Valve function 2/2 directional solenoid valve
Type/operation Spherical seat valve
Basic position De-energized closed NC
Manual actuation Yes
Voltages 24 V DC
Rated current 0.67 A
Rated output 16 W
ON-time 100% ON-time (at max. +35°C)
Protection class IP 65
Electrical connection Plug / DIN DIN 43650-AF3
- 40 -
951-230-008-EN
Version 04
EN
