6. Assembly
IMPORTANT NOTE
Observe technical data (Chapter 4).
6.2.1 Minimum mounting dimensions
To ensure enough space for maintenance
work and for any disassembly of the prod-
uct, ensure that the minimum mounting
dimensions listed below (Figs. 15 and 38)
are maintained.
WARNING
Supply lines or moving parts
When drilling the assembly holes,
you must be careful of any sup-
ply lines or other units, as well as
of other hazards such as moving
components.
Maintain safety clearances and
comply with local regulations for
assembly and accident prevention.
IMPORTANT NOTE
Follow the safety instructions on the lubri-
cant's safety data sheet.
- 48 -
951-230-008-EN
Version 04
EN
The progressive metering device should be
installed in an easily accessible position that
protects it from humidity and vibration.
The minimum installation dimensions
should be adhered to so that all other com-
ponents can be connected later without
problems.
During assembly and during any drilling
work, always pay attention to the following:
o Before installing the progressive meter-
ing device, ensure that all holes, fittings,
and connecting lines in contact with the
progressive metering device are clean and
free of metal chips.
o Existing supply lines must not be dam-
aged by assembly work.
o Other units must not be damaged by as-
sembly work.
o The progressive metering device must not
be installed within range of moving parts.
o The progressive metering device must
be installed at an adequate distance from
sources of heat.
o Maintain safety clearances and comply
with local regulations for assembly and
accident prevention.
