6. Assembly
6.5.6 Consolidation of opposite outlets
It is possible to subsequently connect two
opposite outlets internally by removing a
plug from the right outlet borehole and
closing one of the two outlets.
Fig. 36 VPB consolidati-
on of opposite outlets
20
60
72
Ø7
5
1
3
5
7
9
11
13
15
17
19
2
6
8
10
12
14
16
18
20
Outlet boreholes
At top, viewed
from lubricant
inlet
Plug
917-006-101
(WAF 3)
6.5.7 Consolidation of multiple outlets
(crossporting)
1 outlet
2 outlets
3 outlets
4 outlets
5 outlets
6 outlets
Fig. 37 VPB possible cros-
sporting variations
x
x
x
x
x
x
x
x
x
- 78 -
951-230-008-EN
Version 04
EN
