for oil, attachments 08; 09; 14
6.4.6 VPK progressive metering device with 4/2 or 3/2 directional solenoid valve
Fig. 27 VPK progressive metering device with 4/2 and 3/2 directional solenoid valve
Attachment 08 Attachment 09 Attachment 14
Note
For attachment 09 and attachment
14, the plug screw and the corre-
sponding sealing ring must be or-
dered separately.
De-energized
Minimum mounting dimensions
W = width: 170 mm
H = height 185 mm
L = Length L2+80 mm
- 64 -
951-230-008-EN
Version 04
EN
