4. Technical data
4
4.2.6 VPK progressive metering device with 4/2 and 3/2 directional solenoid valve for oil, attachments 08; 09; 14
VPK 4/2 and 3/2 directional solenoid valve, attachments 08; 09; 14,
Table 15
VPK progressive metering device
For further technical data, see VPK basic design
Thread connection: Inlet: VPKM 10x1
VPKG G1/8“
Ambient temperature range - 15 to + 75 °C
Hydraulic system
Operating pressure max. Oil 150 bar
Lubricant Mineral oils and synthetic oils
Dynamic viscosity 20-1000 mm
2
/s
Electrical system
Directional solenoid valve
(When ordering, please state voltage, type of current, and frequency)
Valve function 4/2 (3/2) directional solenoid valve
Type/operation Pusher/solenoid
Basic position 4/2 open P > A
3/2 open B > T
Voltages 24 V DC
1
)
ON-time 100% ON-time
Protection class IP 65
Electrical connection Plug / DIN 43650
1) Other operating voltage on request
- 41 -
951-230-008-EN
Version 04
EN
