SKF VP Series Component Lifecycle Manual

6. Assembly
IMPORTANT NOTE
Inlet and outlet fittings - see Chapter 12.1.
6.3.2 VP tightening torques
The specified torques must be observed during
assembly and repair.
Tie-rod (starter plate)
(M8)
2.4 Nm ± 0.1 Nm
Nut for tie-rod
(M8)
12 Nm ± 1.0 Nm
Outlet fittings
Type of fitting
Sealing with O-ring 10 Nm ± 1.0 Nm
Sealing with EOlastic ring 10 Nm ± 0.1 Nm
Sealing with copper or alu-
minum ring
15 Nm ± 1.5 Nm
Sealing by sealing edge,
with Loctite 243
15Nm ± 1.5 Nm
Sealing with
Conical nipple
1
)
15Nm ± 1.5 Nm
1) Minimum of 9 Nm at drying time of
> 1h sufficient
VP dimensions
Thread connection
VPM
Inlet:
M14×1.5
Outlet:
M10×1
VPG
G1/4" G1/8"
Type
Number of
progressive
metering
device
sections
Number
of possible
outlets
L1 L2 Weight
[mm] [mm] [kg]
VPM-3 / VPG-3
3 6
84 98 1.73
VPM-4 / VPG-4
4 8
104 118 2.1
VPM-5 / VPG-5
5 10
124 138 2.47
VPM-6 / VPG-6
6 12
144 158 2.84
VPM-7 / VPG-7
7 14
164 178 3.21
VPM-8 / VPG-8
8 16
184 198 3.58
VPM-9 / VPG-9
9 18
204 218 3.95
VPM-10/VPG-10
10 20
224 238 4.32
- 50 -
951-230-008-EN
Version 04
EN
