SKF VP Series Component Lifecycle Manual

6. Assembly
6
P
B
A
T
68
148
BP
VPMVPMVPM
2T3T4T
P
T
B
A
P
T
A
B
P
T
A
B
Fig. 16 VPG progressive metering device
with 2/2 directional solenoid valve
53.5
96
VPMVPMVPM
3T2T4T
Attachment 13
6.3.6 VPG progressive metering device with 2/2 directional
solenoid valve
for oil, attachment 13, 2/2 directional solenoid
valve, de-energized, progressive metering device relieved, only
design VPG
for oil, attachments 08; 09; 14
6.3.7 VP progressive metering device with 4/2 or 3/2 directional
solenoid valve
Fig. 17 VP progressive metering device with
4/2 and 3/2 directional solenoid valve
Attachment 08
Attachment 09
Attachment 14
Note
For attachment 09 and attachment
14, the plug screw and the corre-
sponding sealing ring must be or-
dered separately.
De-energized
De-energized
Minimum mounting dimensions
W = width: 110 mm
H = height 135 mm
L = Length L2+80 mm
Minimum mounting dimensions
W = width: 200 mm
H = height 185 mm
L = Length L2+90 mm
- 53 -
951-230-008-EN
Version 04
EN
