14. Spare parts
Inlet fittings – VPKG (inch thread) and VPKM (metric thread)
Item
Designation
Group VPKG VPKM
[LL] [L] [S] Order No. Order No.
1
Straight connector according to DIN2353, for pipe Ø 6 mm
1
) L 406-403W 406-403
Straight connector according to DIN2353, for pipe Ø 6 mm, tapered
1
) LL - 406-423
Straight connector according to DIN2353, for pipe Ø 8 mm, tapered
1
) LL 408-423W 441-008-511
Straight connector according to DIN2353, for pipe Ø 10 mm, tapered
1
) L 410-443W -
Straight connector, design EO2, for pipe Ø 6 mm 471-006-192 471-006-311
Straight quick disconnect coupling, for pipe Ø 6 mm 406-423W-VS 406-004-VS
Straight quick disconnect coupling, for pipe Ø 6 mm, tapered 406-423W 451-006-518-VS
Elbow connector according to DIN2353, for pipe Ø 6 mm, tapered
1
) L 406-405W 406-405
Elbow connector according to DIN2353, for pipe Ø 6 mm, tapered
1
) LL - 406-425
Elbow connector according to DIN2353, for pipe Ø 8 mm, tapered
1
) LL 408-425W 408-425
Elbow connector for quick disconnect coupling for pipe Ø 6 mm, tapered
1
) 506-511-VS 506-510-VS
Banjo fitting according to DIN2353, for pipe Ø 6 mm
1
) L 445-519-061 445-531-061
Banjo fitting according to DIN2353, for pipe Ø 6 mm
1
) LL - 445-531-062
Banjo fitting for quick disconnect coupling, for pipe Ø 6 mm 506-108-VS 506-140-VS
Banjo fitting for quick disconnect coupling, for pipe Ø 6 mm, tapered
- 455-531-068-VS
1) Solderless screw connection with cutting ring according to DIN 2353
LL series = very light series, L series = light series, S series = heavy series
- 108 -
951-230-008-EN
Version 04
