SKF VP Series Component Lifecycle Manual

14. Spare parts
Progressive metering device components – VPKG (inch thread) and VPKM (metric thread)
Item
Designation
VPKG VPKM
Order No. Order No.
10 Outlet section VPKM-A
11 Inlet plate VPKM.07
12 Intermediate plate VPKM.08
13 End plate VPKM.09
14
Tie-rod for 3 progressive metering device sections, length
80±0.3 mm
VPKM.93
Tie-rod for 4 progressive metering device sections, length
96.5±0.3 mm
VPKM.94
Tie-rod for 5 progressive metering device sections, length
113.5±0.3 mm
VPKM.95
Tie-rod for 6 progressive metering device sections, length
128±0.5 mm
VPKM.96
Tie-rod for 7 progressive metering device sections, length
144±0.5 mm
VPKM.97
Tie-rod for 8 progressive metering device sections, length
162
+
0.5 mm
VPKM.98
Tie-rod for 9 progressive metering device sections, length
178±0.5 mm
VPKM.99
Tie-rod for 10 progressive metering device sections, length
194±0.5 mm
VPKM.100
15 Hexagon nut DIN985-M6-8
- 112 -
951-230-008-EN
Version 04
