4. Technical data
4
4.1.6 VP progressive metering device with flow limiter
1) The values in the table are based on a differential pressure of 20 bar and
viscosity of 300 mm
2
/s. Other differential pressures or viscosities result in
slightly different delivery rates. These can be determined precisely using the
charts for delivery quantities and correction factors for the pressure (see bro-
chure 1-3028-EN).
VP with flow limiter, Table 7
VP progressive metering device
For further technical data, see the VP basic design
Type 2 directional flow control valve
Mounting position Any
Ambient and
lubricant temperature range
0 to 100 °C
Material Steel, galvanized
Weight 0.26 kg
Hydraulic system
Viscosity 20 - 600 mm
2
/s
Nominal volumetric flow See plug-in nozzles table
Operating pressure 5 to 200 bar
Required differential pressure
between inlet p
1
and outlet p
3
≥ 5 bar
Accessories – Table of plug-in nozzles for flow limiters, Table 8
Nominal volumetric flow
1
)
[l/min]
Plug-in nozzle
Ø mm
Order No.
0.081 0.50
24-0455-2574
0.115 0.55
24-0455-2575
0.150 0.60
24-0455-2576
0.207 0.65
24-0455-2577
0.252 0.70
24-0455-2578
0.290 0.75
24-0455-2579
0.345 0.80
24-0455-2580
0.411 0.85
24-0455-2581
0.468 0.90
24-0455-2582
0.559 0.95
24-0455-2583
0.650
1.00
24-0455-2584
0.730 1.05
24-0455-2585
0.794 1.10
24-0455-2586
0.884 1.15
24-0455-2587
0.978 1.20
24-0455-2588
1.087
1.25
24-0455-2589
1) At a dynamic viscosity of 300 mm
2
/s and 20 bar differential pres-
sure; see brochure 1-3028-EN
- 37 -
951-230-008-EN
Version 04
EN
