6. Assembly
IMPORTANT NOTE
Outlets of a progressive metering device
that are not needed must not be closed
because this will cause the progressive
metering device to block. Consolidate un-
needed outlets as described with a neigh-
boring outlet or connect them to the
pump via the return line. Changing the
number of sections and/or metering rate
of individual sections while retaining the
same quantity of grease supply changes
all lubrication quantities of the outlets.
With crossporting, two or more outlets of
an entire progressive metering device side
can be combined as long as there is no
single section in-between. The single sec-
tion completes the group formation; a new
group can only be formed behind the single
section. Two neighboring outlets are con-
solidated from the end section towards the
inlet section.
Procedure:
• Unscrew the appropriate plug
• 917-006-101 using a hexagon socket
screw key (WAF 4).
• Close the outlet borehole with a plug
screw.
The quantity from both outlets will then
flow out of the outlet neighboring the
inlet section.
IMPORTANT NOTE
The progressive metering device sec-
tion behind the inlet section must not be
closed!
- 70 -
951-230-008-EN
Version 04
