MMR2000_113_00_02A.FM VII
Section 07 REAR SUSPENSION
Subsection 01 (SUSPENSION SC-10 SPORT, TOURING AND MOUNTAIN)
SUSPENSION SC-10 SPORT,
TOURING AND MOUNTAIN
Grand Touring 500/580, Formula 500/583 and Summit 500
07-01-1
MMR2000_042_00-02A.FM
A03F24S
Short track models only
Long track
models only
SLE
only
Loctite
271
Loctite
271
Loctite
271
Loctite
271
Loctite
271
Loctite
271
Loctite
271
Loctite
271
Low
temp.
grease
6
5
6
7
4
3
2
1
6
19
Low
temp.
grease
8
9
16
Low
temp.
grease
11
12
13
14
15
11
11
11
16
20
18
10
17
11
18 Nm
(160 lbfin)
4 Nm
(35 lbfin)
Page heading
indicates section
and subsection
detailed.
Bold face number
indicates special
procedure concerning
this part.
Tightening torque nearby
fastener. In this case, nut
must be torqued to
4 Nm or 35 lbfin.
This Shop Manual uses technical terms wich may be
slightly different from the ones in the parts catalog.
Exploded view
assists you in
identifying parts and
related positions.
TYPICAL PAGE
A01A2AS
Illustration number
for publishing
process.
Subsection title
indicates
beginning of the
subsection.
Drop represents
a liquid product
to be applied to
a surface.
In this case
Loctite 271 to
screw threads.
Dotted box contains
parts of a particular
model in this case
the short track
models only.
Page numbering system:
07: REAR SUSPENSION section
01: SUSPENSION SC-10 SPORT,
TOURING AND MOUNTAIN subsection
1: First page of this subsection
Italic subtitle above
exploded view
indicate pertaining
models.
CAUTION: Pay attention to torque
specifi cations. Some of these are
in lbfin instead of lbfft. Use appro-
priate torque wrench.
Document
number for
publishing
process.
INTRODUCTION
