Section 03 TROUBLESHOOTING
Subsection 06 (SUSPENSION AND TRACK)
MMR2000_116_03_06A.FM 03-06-1
SUSPENSION AND TRACK 0
The following chart is provided to help in diagnosing the probable source of troubles. It should be used
as a guideline.
SYMPTOM REAR SUSPENSION BOTTOMS OUT.
CONDITION NORMAL USE.
Test/Inspection 1. Check rear spring preload.
a. Spring tension is too low.
Replace spring or add a shim under torsion spring leg on each side.
SYMPTOM SLIDER SHOES WEAR OUT PREMATURELY.
CONDITION NORMAL USE.
Test/Inspection 1. Check track tension.
a. Pressure is too great on slider shoes.
Adjust according to specifications (refer to TECHNICAL DATA 10). Replace
defective parts.
SYMPTOM PREMATURE WEAR ON TRACK GUIDES.
CONDITION NORMAL USE.
Test/Inspection 1. Check track tension.
a. Pressure is too great on guides.
Adjust according to specifications (refer to TECHNICAL DATA 10).
2. Check slider shoes and/or suspension retaining screws.
a. Worn slider shoes or lost retaining screws.
Replace defective parts and/or tighten loose screws.
