Section 11 WIRING DIAGRAM
Subsection 01 (WIRING DIAGRAM)
MMR2000_137_11_01A.FM 11-01-3
SYMBOLS DESCRIPTION
A00E52S
Beam and tail light
Female terminal Male terminal Electronic module
Meter Electric motor Low level sensor Buzzer
Ignition coil Normally close
switch
Male terminal
on instrument
Engine
ground
Spark plug Meter movement
Bulb Pilot lamp Analog sensor Solenoid valve
Magneto (Delta) 3 position switch Heating element Fuse
Trigger coil Battery Diode
Normally open
switch
Frame
ground
Frame
To Next Page
