3 Scope of Delivery
SMA Solar Technology AG
Operating manualEVC22-3AC-20-BE-en-1016
3 Scope of Delivery
Check the scope of delivery for completeness and any externally visible damage. Contact your
distributor if the scope of delivery is incomplete or damaged.
Figure 1: Components included in scope of delivery
Position Quantity Designation
A 1 Charging station
B 1 Wall mounting bracket
C 1 Strain relief
D 2 RFID charging card (serial number and UID (Unique Identification)
for registering the RFID card to authenticate charging processes)
E 1 3-pole terminal block
F 1 4-pole terminal block
G 2 5-pole terminal block
H 3 Socket head cap screw, M5 x 8
