SMA eCharger - Commissioning the Product

7 Commissioning
SMA Solar Technology AG
Operating manual EVC22-3AC-20-BE-en-10 61
Charging settings Explanation See
5. Standby for charging
process to disconnec-
tion
Time until disconnecting the charging station. Section8.13.1,
page74
6. Lock the charging ca-
ble to the charging sta-
tion
Permanent locking of the charging cable to the
charging station
Section8.13.1,
page74
7.4 Commissioning the Product
NOTICE
Damage to the vehicle during emergency or battery-backup operation
During emergency or battery-backup operation, three-phase loads may be connected to a single-
phase utility grid with phase coupling. This can damage the vehicle.
• Emergency and battery-backup operation must be clarified with and approved by the
vehicle manufacturer in advance.
• Ensure that, during phase coupling, only single-phase loads are connected to the battery-
backup grid.
Observe the following information about the charging cable
• Always pull the charging cable out of the port by the connector, never by the cable itself.
• The charging cable must not be mechanically damaged (kinked, pinched, or run over)
and the contact area must not make contact with heat sources, dirt, or water.
• Never use defective, worn, or dirty charging plugs.
• Do not use extension cord sets.
• Do not use adapters of any kind.
• Follow the information and manuals for your vehicle before using the charging station to
charge the vehicle.
• Use the protective cap when the charging cable is not in use.
• Do not put the charging cable under tension. Do not touch the pin contacts.
• Avoid knots in the charging cable.
• Unwind the charging cable all the way when charging.
• The charging cable is a trip hazard when lying on the ground. Store the charging cable
properly or use the cable hanger when the charging process is completed.
Requirements:
☐ The AC circuit breaker must be correctly rated and mounted.
Information: the charging station does not have a dedicated disconnect switch. The miniature
circuit breaker in the supply line serves as a disconnect device.
☐ The product must be correctly mounted.
