C H A P T E R 3
Using your interactive projector
26 smarttech.com/kb/170295
Setting Use Notes
Startup Screen Opens the Startup Screen sub-
menu where you can select the
type of startup screen (SMART or
USER), capture an image to use for
your startup screen and preview the
current startup screen.
The default is SMART.
This screen displays when the
projector lamp is starting and a
video source signal isn’t
displayed.
SMART displays the default
SMART logo on a blue
background.
USER displays an image you
capture or select. If no image is
selected, a default image
displays.
Capture User Startup Screen
closes the on-screen display
menu and captures the entire
projected image. The captured
image is displayed the next time
the Startup Screen displays.
(The capture can take up to one
minute, depending on the
complexity of the background
graphic.)
Preview Startup Screen
enables you to preview the
default or captured startup
screen.
Test Screen
Opens the Test Screen sub-menu
where you can select the type of
screen test
(Display Grid, Display
Multi-Square Pattern, Display
Checkerboard 1, Display
Checkerboard 2 or Display
Single Square). Select Exit to
close the menu.
This screen enables you to
quickly check display
performance. Select a test type,
and then press ENTER on the
remote control. Press ENTER
again to exit the test and return to
the Test Screen sub-menu.
Display Grid displays a 7 × 7
Grid test screen.
Display Multi-Square Pattern
displays a 45 Square test screen.
Display Checkerboard 1
displays a Check1 test screen.
Display Checkerboard 2
displays a Check2 test screen.
Display Single Square displays
a Spot test screen.
