The individual elds on this screen are dened as follows:
Field Name Description
Mode Displays the service type (ADSL_2plus, VDSL2)
Trac Type Displays the connection type (ATM, PTM, ETH
Status Displays the status of the connection (Up, NoSignal, Initializing)
Link Power State Link output power state
Line Coding (Trellis) (Downstream/Upstream) Displays the state of Trellis Coded Modulation (On, Off)
SNR Margin (db) (Downstream/Upstream) Signal to Noise Ratio
Attenuation (db) (Downstream/Upstream) Estimate of average loop attenuation
Output Power (dBm) (Downstream/Upstream) Transmit power from the gateway to the DSL loop.
Attainable Rate (Kbps) (Downstream/ Upstream) The typically obtainable sync rate.
PhyR Status [Inactive, Active] Physical Layer Retransmission feature status. (Downstream/ Upstream)
Rate (Kbps) (Path 0/1, Downstream/Upstream) Current sync rate
MSGc (# of bytes in over-
head channel message)
(Path 0/1, Downstream/Upstream)
B (# of bytes in Mux
Data Frame)
(Path 0/1, Downstream/Upstream)
M (# of Mux Data Frames
in FEC Data Frame)
(Path 0/1, Downstream/Upstream)
T (Mux Data Frames
over sync bytes)
(Path 0/1, Downstream/Upstream)
R (# of check bytes
in FEC Data Frame)
(Path 0/1, Downstream/Upstream)
S (ratio of FEC over PMD
Data Frame length)
(Path 0/1, Downstream/Upstream)
L (# of bits in PMD
Data Frame)
(Path 0/1, Downstream/Upstream)
D (interleaver depth) (Path 0/1, Downstream/Upstream)
Delay (msec) (Path 0/1, Downstream/Upstream)
INP (DMT symbol) (Path 0/1, Downstream/Upstream)
Super Frames (Path 0/1, Downstream/Upstream) Total number of super frames.
