The individual elds on this screen are dened as follows:
Field Name Description
VPI [0-255] Enter a Virtual Path Identier. VPI is an 8bit identier to uniquely identify a network path for
ATM cell packets to reach its destination. Every ATM path requires a unique VPI number to associate.
Works together with the VCI. Each individual DSL circuit cannot have the same VPI/VCI combination.
VCI [32-65535] Enter a Virtual Channel Identier. VCI is a 16bit identier that has a unique channel.
Select DSL Latency [Path0 Fast] No error correction and can provide lower latency on error free lines.
[Path1 Interleaved] Error checking that provides error free data which increases latency.
[Path0&1 Both] Fast & Interleaved
