The individual elds on this screen are dened as follows:
Field Name Description
Select DSL Latency [Path0 Fast] No error correction and can provide lower latency on error free lines.
[Path1 Interleaved] Error checking that provides error free data. This tends to increases
latency.
[Path0&1 Both] Fast & Interleaved.
Weighted Round Robin Time slices are assigned to each process in equal portions and in circular order, handling
all processes without priority (also known as cyclic executive).
Weighted Fair Queuing A data packet scheduling technique allowing different scheduling priorities to statistically
multiplexed data ows. Since each data ow has its own queue, an ill-behaved ow (who
has sent larger packets or more packets per second than the others since it became ac-
tive) will only punish itself and not other sessions.
Default Queue Weight [1-63] Enter a default weight of the specied queue.
Default Queue Precedence [1-8] Enter a precedence for the the specied queue.
Default Queue Minimum Rate [1-0 Kbps] The default minimum rate at which trac can pass through the queue.
[-1 Indicates no shaping.]
Default Queue Shaping Rate [1-0 Kbps] The shaping rate for the specied queue.
[-1 Indicates no shaping.]
Default Queue Shaping Burst Rate [>= 1600] The maximum rate at which trac can pass through the queue.
