Page 55

501 SE Columbia Shores Boulevard, Suite 500, Vancouver, Washington 98661, USA l +1 360 859 1780

Field Name Description

Classication Name A free form text eld. Enter a descriptive name for this rule.

Rule Order [Last, Null] Select Last to set this rule as the very last classication rule to be processed.

Select Null to set this rule as the next classication rule to be processed within the exist-

ing list of classication rules.

Rule Status [Enable, Disable] Select whether this rule is active or turned off.

Class Interface [local, eth0..eth4, wl0] Select an interface.

Ether Type [IP, ARP, IPV6] Select the Ethernet interface type for this classication.

Source MAC Address

Source MAC Mask

Enter the source MAC Address and Source MAC Mask applied to classication.

Destination MAC Address

Destination MAC Mask

Enter the destination MAC Address and destination MAC Mask applied to classication.

Source IP Address/Mask Enter the source IP Address and Source IP Mask applied to classication.

Destination IP Address /Mask Enter the source IP Address and Source IP Mask applied to classication.

Protocol (Optional) Enter the Protocol specied for classication criteria.

UDP/TCP Source Port (Optional) Enter the Source Port applicable for classication criteria. Expressed as a range

or single port. (port:port or port).

UDP/TCP Destination Port (Optional) Enter the Destination Port applicable for classication criteria. Expressed as a

range or single port. (port:port or port).

Specify Class Queue Choose from available queues in the drop-down list.

Packets classied into a queue that exit through an interface for which a queue is not

specied to exist, will instead egress to the default queue on the interface.

Mark Applied Differentiated Service

Code Point

Select the desired DSCP code from the drop down list.

802.1P priority [1-7] (Lower values have higher priority.) This value is inserted into the Ethernet frame to

be used by QoS disciplines to differentiate trac.

Rate Limit (kbps) Data trac rate limit applied to classication.

The individual elds on this screen are dened as follows:
