DDAAWW CCoonnttrrooll
33--3355
AAssssiiggnniinngg aa PPlluugg--IInn oorr HHaarrddwwaarree II//OO IInnsseerrtt ((AAssssiiggnn MMooddee))
To Assign a Plug-in to a Channel Insert Point:
1. Press the ASSIGN soft button to enter assign mode; the on-screen box flashes to confirm this.
2. Press the D-pot corresponding to the insert slot that you want to route to a plug-in (use the paging buttons
as necessary) then use the D-pot to scroll through the list of plug-ins and I/O slots; the displayed names are
derived from the DAW.
3. To confirm the assignment either:
a. Press the ASSIGN button a second time. This will exit INSERT mode and switch the Plug-In Editor
to PARAMETER mode to edit the last selected insert, or
b. Press the D-pot used to make the assignment. This will confirm the assignment and leave you in Assign
mode for further assignments.
Some DAW applications will not allow assignments to be made during playback or recording.
Assigning the Same Plug-in to All Channels
Follow steps 1 and 2 above to select a plug-in, then hold down the OPTION button before pressing the D-pot
switch to assign that plug-in to all channels.
Assigning The Same Plug-in to Selected Channels
To assign a plug-in to selected channels, select SEL mode on the Master Control Panel then choose the channels
you wish to assign to by holding down SHIFT and pressing the channel SEL buttons.
Follow steps 1 and 2 above to select a plug-in, then hold down OPTION + SHIFT before pressing the D-pot
switch to assign the plug-in to the selected channels.
EEddiittiinngg PPlluugg--IInn PPaarraammeetteerrss ((PPaarraammeetteerr MMooddee))
Selecting a Plug-In to Edit
In Insert or Assign mode, press the plug-in D-pot for the insert you wish to edit or in Insert mode, select
Parameter mode by pressing the INSERT/PARAM soft button. To exit from Parameter mode, press the
PARAM soft key (if you want to edit a different plug-in) or the ASSIGN soft key (if you want to change
assignment).
Changing Plug-in Parameters
Once you have selected a channel and a plug-in for editing, the four D-pots and their switches control the on-screen
parameters derived from the DAW plug-in. The names of the currently selected controls and their values are shown
above the on-screen D-pots. The PAGE UP and PAGE DOWN buttons can be used to access all the plug-in
controls.
Hi-Resolution Parameter Display Mode
Holding down the OPTION button while editing a plug-in parameter will show a 9-character version of the
parameter value at the top of the Plug-In Editor display.
The ALT button can be used to open or close the plug-in/pop-up window at any time
DDuuaalliittyy SSEE OOppeerraattoorr’’ss MMaannuuaall
