Talkback
Talkback switches: Select the operation of the talkback buttons: Momentary / Latching
/ Auto (Play) / Auto (Record).
Listen switch: Select the operation of the Listen buttons: Latching / Auto (Play) /
Auto (Record).
Red light switch: Select the operation of the Red Light switch: Manual / Auto (Play) /
Auto (Record).
TB switches disable Listen: This allows the Listen function to be switched off when talkback is
activated, thus avoiding feedback problems.
TB to FB: (Sums / Replaces) When assigning talkback to foldbacks, this option
defines whether talkback sums with or replaces the normal foldback
signal.
See Communications for more details of these options
Monitor section
Monitor Gain Display: The calibration of the main monitor Gain pot and display can be set
to one of three industry-standard monitoring modes: Music (Off to
11) / Film (Off to 95dB) / Gain (Off to 0dB)
Monitor Set CAL level: When in Film monitoring mode, the calibrated listening level can be
adjusted: 70 - 90 (dB).
See Monitor Level Display and Calibrated listening level for more details of these options
Solo Gain boost: When auditioning signals which are low in the mix, it is possible to
boost the solo bus signal level (Range: 0-10dB).
Isolated channels AFL on solo: Set solo-isolated channels to automatically solo in AFL (ON/OFF).
Desk Setup
Stereo Mix Insert Mode This enables the stereo mix matrix ‘SUM’ option to be selected,
where the insert return sums with the main signal path. Select
REPLACE to disable this function.
Input Cut Enable If set ON, the channel strip CUT button will cut prefade sends, ie.
Aux and CHOP sends (ON / OFF).
Analogue Meter Scaling Set the analogue level corresponding to 0dBfs on the console meters.
(Range 18, 20, 22, 24 dBu).
22--4444
CCoonnssoollee OOppeerraattiioonnss
DDuuaalliittyy SSEE OOppeerraattoorr’’ss MMaannuuaall
