The majority of DAW functions are controlled via dedicated Duality SE front panel switches, with less reliance than
the HUI protocol on the 8x8 soft key matrix located beneath the TFT screen. All plug-in editing is via the channel
D-pots. The four encoders, together with the six switches below the centre section monitor screen, are not used.
On the channel fader strips, the fader button and associated status LEDs are also not implemented by the protocol.
All other controls, the D-pot and associated push switch, DAW channel Solo and Cut, plus the Select and Ready
functions, are all fully supported. Only mono metering information is returned from the workstation. On stereo
channels, the maximum value of the left or right channel is displayed. The master fader is also included in the DAW
layer when a Mackie Control template is active.
The AUTO, PRE, IN, OUT etc. group of centre section buttons provide different related motion control functions
according to the active template.
The jog wheel, together with the SCRUB button, plus the cursor buttons and cursor mode switch, are active in
all templates. The outer jog wheel ring is not supported, neither is the numeric keypad. However the 1-8 keys
replicate F1 - F8 function keys in certain templates.
33--4466 DDuuaalliittyy SSEE OOppeerraattoorr’’ss MMaannuuaall
DDAAWW CCoonnttrrooll
