To adjust balance of a link, hold one fader whilst moving another. This automatically isolates the second fader from
the link whilst the remaining faders continue to track the first fader touched.
When the Links page is not active, pressing the SHOW LINKS button to the left of the Eyeconix button causes
the Links to be displayed in the Scribble Strip.
The SHOW LINKS button is automatically selected when the Links page is active.
As far as the automation system is concerned (see Section5), switch and fader operations performed in one channel
will cause that function in every channel in the link to go into Write. Links can be dissolved at any time, but all the
automation data will still play out correctly.
To edit any existing links, scroll to and select the link. Channels can be added
or removed as described above.
SuspdSel/SuspdAll
Links can be globally or individually suspended at anytime. A link that is
suspended will allow you to move all the faders in the link independently. If a
link is highlighted, then the SuspdSel key will deactivate the selected link and
‘suspended’ will be shown next to the link number. SuspdAll suspends all
links in the list. The ‘Motors Off’ function automatically activates the SuspdAll
function.
Inverting Switch Links
To invert the state of any switch in a link suspend the link, press the switch to
toggle it to the opposite state, then re-enable the link.
Deleting Links
To delete a link, select and highlight it, then use the Delete and Confirm keys.
Fader
Status
Button
22--1133
CCoonnssoollee OOppeerraattiioonnss
DDuuaalliittyy SSEE OOppeerraattoorr’’ss MMaannuuaall
