If either MINI A or MINI B ‘LS SELECT’ buttons are selected, the left and right monitor busses are fed to the
corresponding stereo mini loudspeaker output. Mini level relative to the main monitors can be trimmed via the
main monitor pot by selecting MINI in the group of buttons to the right of the monitor pot. When a Mini speaker
output is selected, the 5-2 STEREO mix is automatically switched into the monitor circuit to deal with any 5.1
sources present.
The DIM button dims both main and mini loudspeaker outputs by a preset level. Set this level by selecting the
DIM button to the right of the monitor pot and turning the main monitor pot. The Dim circuit is automatically
activated when any of the following buttons are pressed: LISTEN, TB ALL, F/B A, F/B B, EXT T/B,
Oscillator to TRACK or MIX.
The CUT button cuts the monitor feeds to whichever set of monitors is selected. CUT is activated automatically
by the SLATE talkback function. CUT and DIM can also be activated externally via the GPIO/Talkback connector.
The six main monitor outputs can be muted individually with the L, C, R, LS, RS and LFE (sub) ‘MONITOR
MUTE/SOLO’ buttons. These become monitor solo buttons by selecting the SOLO button in the ‘MON MODE’
group (see above).
All the monitor outputs are available for connection to amplifiers via the centre section connector panel. The two
5.1 outputs (Main and Alt) and the two Mini outputs feed two 25-way D-type connectors — ‘MON A’ and ‘MON
B’; the two Mini outputs (Mini A and Mini B) also feed individual XLRs for left and right.
External Source Selectors
Two external monitor source selectors are provided. EXT A has four 5.1 inputs. These may be fed by any source
of six channels or less. The MIX selection provides an important fifth input to EXT A, which is used to monitor
the 5.1 Main Mix bus when mixing in 5.1 mode.
EXT B is a 2-channel selector that may receive up to four stereo sources. In either case, sources may be summed
together; this is particularly useful for generating complex foldback mixes or when stem mixing, as it allows the
recorded stems to be monitored together with the current mix.
To select an external monitor source, first press either the EXT A or EXT B button , choose a source from those
shown in the display, and then press the soft key under that source (or first press the key under SUM to sum
selected sources). Finally, route the external source(s) to the monitors by pressing EXT A or EXT B in the ‘MON
SRC’ group of buttons. The LTR selection on EXT B provides monitoring for a surround encoder’s LtRt output
(see next page).
Inputs to the external source selectors are connected via D-connectors (four for External A, one for External B)
on the connector panel.
22--2255
CCoonnssoollee OOppeerraattiioonnss
DDuuaalliittyy SSEE OOppeerraattoorr’’ss MMaannuuaall
