BMN — Turns on the Bass Management system. This is designed to extend the low frequency response of the
monitoring system, and to simulate the 5.1 monitoring systems in TV and domestic environments. It inserts 12dB
per octave, 80Hz high pass filters in the L, C, R, LS, RS monitor outputs, and feeds a pre high pass filter mono sum
of these five outputs to an 80Hz, 24dB per octave, low pass filter, which is summed with the LFE monitor bus. Post
this summing point, the combined signals feed via a 10Hz subsonic high pass filter before reaching the subwoofer
monitor output. These are the default filter slopes. Internal circuit-board links (see Installation Guide for details) allow
the links to be set to 12dB or 24dB per octave, and to select whether or not the surround channels are included.
Note that this option is stored separately for each set of speaker outputs (like the loudspeaker level
calibration), so it is possible to have Bass Management enabled on one set of speakers and not on others.
LF0 — Normally, the LFE bus level is increased by 10dB post the main monitor level control, as this is a requirement
for DVD playback. If you are mixing for SACD, or any other format that requires unity gain on the LFE channel, select
LF0 to restore the LFE bus level to unity gain.
NEXT — Produces a second layer of options:
A2B — Retains use of the main 5.1 subwoofer, even when you switch to the ALT 5.1 loudspeaker selection.
BMA — Uses the Alt 5.1 subwoofer instead of the main subwoofer for bass management when MINI A is selected
and BMN is on.
BMB — Uses the Alt 5.1 subwoofer instead of the main subwoofer for bass management when MINI B is selected
and BMN is on.
RTRN — Returns you to the top layer of the MONITOR OPTIONS selection.
22--2288
CCoonnssoollee OOppeerraattiioonnss
DDuuaalliittyy SSEE OOppeerraattoorr’’ss MMaannuuaall
