DDAAWW CCoonnttrrooll
33--55
CCoonnnneeccttiinngg DDuuaalliittyy SSEE ttoo DDAAWWss
Duality SE communicates with connected DAWs using MIDI ports – either MIDI over Ethernet (ipMIDI) or the
physical MIDI ports located on the rear of the console. This is selected in SSL/Misc/Setup/MIDI connects via.
A number of items in the SSL / Misc / Setup menu, accessed via the centre section TFT, are concerned with DAW
interconnection.
To change a setting, use the left hand D-Pot to select the item, then press the D-Pot to enter adjustment mode. Turn
the D-Pot to the desired setting and press it a second time to save the setting to non-volatile memory.
DAW 1 Jog wheel sends: Define the control data sent by the jog wheel for HUI DAWs. Options
are Jog / Nudge (40 / 20 / 13 / 10 / 8 / 6 / 5 per revolution).
First physical channel DAW 1: Select the console channel number that is controlling the first DAW track
number for DAW 1.
Channel Count DAW 1: Select the total number of channels dedicated to DAW 1 control (8-48
in steps of 8). If you change these figures, you will need to change the
number of controllers assigned in the DAW.
Note that these entries also exists for DAW 2 where applicable.
Single Layer: Allows both DAWs to appear on different channel ranges within DAW
layer 1. Ensure that the channel range for DAW 2 starts after the range
for DAW 1.
Note that changes to any of these settings will require a console reboot before they take effect: hold down the
Restart softkey and press the Confirm softkey which appears to its right.
Refer to your DAW manual for information on how to configure its software. Once configured and connected,
communication with the DAW will be initialised, and the level of Duality SE’s channel faders, rotary controls and
master functions will be set to match the DAW controls (provided you are ‘DAW Focus’ mode).
DDuuaalliittyy SSEE OOppeerraattoorr’’ss MMaannuuaall
