SOLO BETA User Manual
In Closed-loop mode of AC Induction Motors:
it will act as the reference for magnetizing current reference known as “Id” which is in charge of
generation of stator flux. The maximum amount of current that can be injected into the motor
using this pin is 10Amps. So in order to calculate the amount of magnetizing current you can use
the following formulas:
In case of using PWM:
The Magnetizing current value = ((100 - duty cycle of PWM at P/F input)/100) * 10.0
In case of using Analogue Voltages:
The Magnetizing current value = ((5.0 - the voltage at P/F input)/5.0) * 10.0
