Solo BETA - Connectors and Sections

SOLO BETA User Manual


Connectors and Sections:



 


www.solomotorcontrollers.com
January 2021 - Revision V_1.0.5 Copyright © 2020, All right Reversed. SOLO motor controllers.

10
Section 1 - Motor Output
PIN
Name
Descriptions / Notes
I/O
1
A
Motor Output 1
-
2
B
Motor Output 2
-
3
C
Motor Output 3
-
Section 2 - Supply Input
PIN
Name
Descriptions / Notes
I/O
1
++
Positive Voltage Input
-
2
- -
Negative Voltage Input ( Ground )
-
Section 3 - Analogue Inputs and +5V External Supply
PIN
Name
Descriptions / Notes
I/O
1
GND
Analog Ground of SOLO
-
2
DIR
Direction of rotation of the motor control
I
3
P/F
Current Limit, Power or Flux reference
I
4
S/T
Speed or Torque reference
I
5
+5V
Supply output for external modules ( fused at 1A)
O
