118 Chapter 5: DICOM Connectivity
DICOM
The following table identifies the parameters used for worklist queries.
To configure a new worklist server:
1 Ensure the TITAN system is set up for DICOM connectivity. See “To set up the TITAN system
for DICOM connectivity:” on page 105.
2 Press the Setup key and select Connectivity and then DICOM Setup.
3 Select Config from the on-screen menu.
4 In the Configure list, select Worklist Servers.
5 Select New.
6 Enter information in the fields (pages 1 and 2).
• The Name cannot contain special characters.
• The Alias and AE Title may contain special characters.
• The IP address and port must be entered before the information is saved.
Note: To use special characters, select Symbols. See “To enter a symbol/special character:” on page 20.
Note: Use the space bar on the keyboard to enter the underscore symbol.
Select Cancel to undo last change.
7 Select Save.
8 Complete all configuration information and then select Done from the on-screen menu.
A dialog box is displayed to restart the system.
To set up an automatic query update:
1 Press the Setup key and select Connectivity and then DICOM Setup.
2 Select Config from the on-screen menu.
3 In the Configure list, select Worklist Servers.
4 In Automatic Query (page 2), select On.
5 In the Occurs Every list, select the desired length of time between automatic updates.
6 In the Start Time list, select the start time for the automatic updates.
7 Select Done from the on-screen menu.
A dialog box is displayed to restart the system.
Table 1: Manual and Automatic Query Parameters
Item
Manual
Patient Query
Manual
Update from
Worklist
Automatic
Query Update
Patient data X
Date Range X X X
This TITAN Only X X
Automatic Query On/Off X
Occurs Every X
Start Time X
