Chapter 4: Measurements and Calculations 91
Meas. & Calcs
Label Vascular
Measurement
1 On a frozen Doppler spectral trace, press the Calcs key.
Use the touchpad to highlight Left or Right from the calculation
menu.
2 Press the Select key.
3 Use the touchpad to highlight the desired measurement from the
calculation menu.
4 Press the Select key.
5 Use the touchpad to position the caliper at the peak systolic wave
form.
6 Press the Select key.
A second caliper is displayed on the screen. The active caliper is
highlighted green.
7 Use the touchpad to position the second caliper at end diastole on the
waveform.
The results are displayed in the measurement and calculation data
area and are updated as the caliper moves.
8 Select Save from the on-screen menu, or press the Enter key to save
the measurement to the patient report.
The saved measurement is displayed at the bottom of the calculation
menu and a check mark is put in front of the measurement.
If desired, press the Save key to save the image with the
measurements displayed.
Note: The key or Save Key can be assigned in system setup to save
calculations to the report. See “Delta Key” on page 32 or “Save Key” on
page 39.
9 Repeat these steps until all measurements have been performed.
View or Repeat
Saved
Measurement
1 Use the touchpad to highlight the desired measurement from the
calculations menu.
The saved measurement is shown at the bottom of the calculation
menu.
2 Press the Select key or the Caliper key to select the measurement.
3 Repeat the measurement.
The new results appear in the measurement and calculation data area.
You can compare the active measurement to the saved measurement.
4 To save a new measurement, select Save from the on-screen menu, or
press the Enter key.
Note: This will save the new measurement to the patient report and
overwrite the previously saved measurement.
Note: You must remeasure systolic measurement to remeasure diastolic
measurement.
Delete
Measurement
1 Use the touchpad to highlight the measurement.
2 Select Delete from the on-screen menu.
This will remove the last saved measurement from the patient report.
