73
Using as a Video Process Controller
If you pressed the TRIM+ button in step 2
PDW-HD1500
If you pressed the TRIM– button in step 2
1)
This does not function when the VID.PROC function menu item of
the PDW-HD1500 is set to MENU.
If you pressed the TRIM+ button in step 2
1)
This does not function when the VID.PROC function menu item of
the PDW-HD1500 is set to LOCAL.
4 Change the value.
You can change the setup level in the range of ±10IRE,
you can also change the black level in the range of
±70 mV. When the system frequency of the HDW-
S280 is set to 23.98, you can change the setup level in
the range of ±3.3IRE.
To change the value using the TRIM+ button
or TRIM– button
TRIM+ button: Each time you press this button, the
value increases.
TRIM– button: Each time you press this button, the
value decreases.
To change the value using the search dial
Press the ALL STOP button. You can use the search
dial to change the value.
To reset to the preset value
Press the RESET button.
To cancel the video process control mode
Press the buttons you pressed in step 2, again.
HD output SD output
A1 button Y level
–
A2 button Pb level
A3 button Pr level
A4 button Setup level
– : Not changed
HD output SD output
A1 button
Video level
1)
Video level
A2 button
Chroma level
1)
Chroma level
A3 button
Hue
1)
Chroma phase
1)
Hue
Chroma phase
A4 button
Setup level
1)
Black level
1)
Setup level
Black level
HD output SD output
A1 button
Y level
1)
–
A2 button
Pb level
1)
A3 button
Pr level
1)
A4 button
Setup level
1)
– : Not changed
Note
