2-8. DIGITAL BOARD BLOCK-2
2-9. DIGITAL BOARD
2 screw
(BV3 u 8CU)
2 two screws
(BV3 u 8CU)
3 seven screws
(B3 u 5)
5 DIGITAL board block
– Rear view –
4 Remove the DIGITAL board block
in the direction of an arrow.
1 screw
(BVTP3 u 8)
1 screw
(BVTP3 u 8)
3
boss
3
boss
4
bracket (4F digital) block
7
HDMI heat sink
8
radiation sheet
9
DIGITAL board
1
screw
(BV3
u
8CU)
1
screw
(BV3
u
8CU)
1
screw
(BV3
u
8CU)
1
screw
(BV3
u
8CU)
1
screw
(BV3
u
8CU)
1
screw
(BV3
u
8CU)
2 clamp
2 clamp
2 clamp
5 cover (indicator-rear) block
6 Bent two claws are returned
to a straight form.
(ZA3000ES)
