STR-ZA1000ES/ZA2000ES/ZA3000ES
6
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
2-3. CASE, FUSE (F01)
(Page 7)
2-4. FRONT PANEL BLOCK-1
(Page 8)
2-5. FRONT PANEL BLOCK-2
(Page 9)
2-6. POWER UNIT BLOCK (ZA3000ES)
(Page 10)
2-7. DIGITAL BOARD BLOCK-1
(Page 11)
2-8. DIGITAL BOARD BLOCK-2
(Page 12)
2-11. DCDC BOARD BLOCK-2
(Page 14)
2-12. STBY BOARD BLOCK
(Page 15)
2-13. AC INLET (2P) BLOCK
(Page 16)
2-18. GND BOARD
(Page 21)
2-9. DIGITAL BOARD
(Page 12)
2-10. DCDC BOARD BLOCK-1
(Page 13)
2-22. AMP BOARD BLOCK-1
(Page 25)
2-15. A-VIDEO BOARD BLOCK-1
(Page 18)
2-16. A-VIDEO BOARD BLOCK-2
(Page 19)
2-19. AUDIO BOARD BLOCK-1
(Page 22)
2-20. AUDIO BOARD BLOCK-2
(Page 23)
2-21. TUNER ASSY (TU1)
(Page 24)
2-17. A-VIDEO BOARD
(Page 20)
2-23. AMP BOARD BLOCK-2
(Page 26)
2-25. SPTM BOARD
(Page 27)
2-24. AMP BOARD
(Page 27)
2-14. PRE-OUT BOARD (ZA3000ES)
(Page 17)
2-2. FRONT COVER ASSY
(Page 7)
SET
