Sony STR-ZA2000ES - Power Unit Section

94
STR-ZA1000ES/ZA2000ES/ZA3000ES
7-2. POWER UNIT SECTION
* 51 3-703-150-11 CLAMP (ZA3000ES)
52 4-565-269-01 CUSHION (SPACER) (ZA1000ES)
0 PU1 1-474-585-11 POWER UNIT (ZA3000ES)
#1 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
(ZA1000ES)
(ZA2000ES/
ZA3000ES)
(ZA2000ES/
ZA3000ES)
#1
PU1
#1
#1
#1
#1
#1
#1
#1
#1
#1
not
supplied
not supplied
not supplied
not supplied
not
supplied
51
51
DISPLAY board section
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
1
2
3
DIGITAL board section
(ZA3000ES)
2
1
3
52
52
Ver. 1.1
