Sony STR-ZA2000ES - AMP Board; SPTM Board

STR-ZA1000ES/ZA2000ES/ZA3000ES
27
2-24. AMP BOARD
2-25. SPTM BOARD
2
two screws
(BVTP3
u
8)
1
Remove forty-two
solders.
4
AMP boar
d
3
heat sink block
– AMP board block rear view –
4 seven screws (BV/ring)
1 screw
(BVTP3 u 8)
3 screw
(BVTP3 u 8)
3 screw
(BVTP3 u 8)
– Rear view –
5 Remove the SPTM
board in the direction
of an arrow.
6 SPTM board
SPTM board
A
A
1 Remove the wire
from two lead pins.
(See Fig. F)
2
connector
(CN951)
lead pinpower transformer (T01)
lead pin
:LUHVHWWLQJ
)LJ)!
