Sony STR-ZA2000ES - AUDIO Board Section

99
STR-ZA1000ES/ZA2000ES/ZA3000ES
7-7. AUDIO BOARD SECTION
301 A-2039-513-A AUDIO BOARD, COMPLETE (ZA3000ES)
301 A-2039-527-A AUDIO BOARD, COMPLETE
(ZA1000ES/ZA2000ES)
302 4-974-510-11 SCREW (+BV 3X8 CU)
303 4-249-675-02 +BV SUMITITE S 4X6 ROUND
CN2700 1-822-149-11 D-SUB CONNECTOR 9P (Including two screw nuts)
(RS232C)
FFC2 1-921-391-52 FFC 19P (130)
FFC3 1-921-391-62 FFC 29P (130)
#1 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
power transformer section
supplied
with CN2700
– Rear view –
301
302
302
302
302
302
302
302
302
303
not supplied
not supplied
FFC3
#1
#1
#1
#1
#1
not supplied
not supplied
not supplied
not supplied
(GND board)
FFC2
303
302
302
(ZA3000ES)
wg
wh
wg
wh
wj
wj
wl
supplied
with CN2700
CN2700
wk
wk
wl
e;
e;
(ZA1000ES/ZA2000ES)
(ZA1000ES/
ZA2000ES)
Ver. 1.1
