The System commands reset the system and return system-related information.
Table 3-12: Synchronization Commands
Header Description
The Waveform commands control the transfer of, and parameters related to the
transfer of, waveform-related information between the VX4792 Arbitrary
Waveform Generator and external controller. This information includes unscaled
waveform data, the waveform preamble that specifies how to reconstruct the
waveform data, equations defining waveforms, and formats for transferring
waveforms. Consider the following points when using waveform commands:
H Waveform data transferred includes only raw, binary-formatted data; the
preamble contains the data-encoding format, waveform scale, and related
data that allow a scaled waveform to be obtained
H The command or query transfers the unscaled waveform, marker, and
sequence data
H The command or query transfers both the waveform and the
preamble
H The commands and queries set up the waveform preamble
H The commands and queries specify the format and location of the
waveform and marker data
H The commands define, compile, and otherwise control the
conversion of an equation expression into a waveform
System Commands
Waveform Commands
