Sony Tektronix VX4792 - Figure 2-18: Trigonometric Function Waveform; Figure 2-19: Trigonometric Function Waveform Expressed with Variable T

Functional Overview
2-22
VX4792 User Manual
+1.0
-1.0
Equation: range(0,100ms)<LF>cos(2*pi*x)
1000 Points ; Clock 1e+07 Hz
Figure 2-18: Trigonometric Function Waveform Expressed with Variable x
+1.0
-1.0
Equation: range(0,100ms)<LF>sin(2*pi*1e4*t)
1000 Points ; Clock 1e+07 Hz
Figure 2-19: Trigonometric Function Waveform Expressed with Variable t
