Functional Overview
VX4792 User Manual
2-3
 
 
 
 
 
 

 

 
 
 
 
 
 
 
 
 
 
 
Figure 2-1: Front Panel Connectors and Indicators
Generating Waveforms
Waveform data must be loaded into the internal memory of the VX4792 Arbi-
trary Waveform Generator before the waveform generator can produce output
waveforms. Waveform data is obtained from the four types of waveform files
shown in Table 2–1.
