VX4792 User Manual
3-13
Command Groups
The Command Groups section divides the organization of the waveform
generator command set into functional groups. (See Command Descriptions
beginning on page 3–21 for a complete description of each command in
alphabetical order.)
A command quick reference (page 3–14) that summarizes the commands
available for the VX4792 Arbitrary Waveform Generator has been provided for
your convenience. We encourage you to duplicate the command quick reference
for easy access to the complete list of commands.
Throughout this section, the parenthesized question symbol (?) follows the
command header to indicate that both a command and query form are included
for the command.
Commands Grouped by Function
Table 3–4 lists the nine functional groups into which the commands are
classified.
Table 3-4: Function Groups in the Command Set
Group Functions Controlled
Calibration and Diagnostic Control calibration and selfĆtest diagnostics according to
selected routines
Memory Control internal memory operations
Mode Control operating mode and set trigger parameters
Output Turn output waveform on and off and select the sync
signal position
Setup Select clock source and its parameters
Status and Event Set and query the registers and queues of the reporting
system
Synchronization Control operation complete and pending command
execution
System Control miscellaneous instrument functions such as data
and time, local lockout, query response forms, and
instrument ID
Waveform Control transfer of waveforms
