Sony Tektronix VX4792 - Table 2-9: Right Slot P1 Pinout

Instrument I/O
2-36
VX4792 User Manual
Table 2-9: Right Slot P1 Pinout
Pin Number
Row A
Signal Mnemonic
Row B
Signal Mnemonic
Row C
Signal Mnemonic
1 D00 BBSY D08
2 D01 BCLR D09
3 D02 ACFAIL D10
4 D03 BG0IN D11
5 D04 BG0OUT D12
6 D05 BG1IN D13
7 D06 BG1OUT D14
8 D07 BG2IN D15
9 GND BG2OUT GND
10 SYSCLK BG3IN SYSFAIL~
11 GND BG3OUT BERR~
12 DS1 BR0 SYSRESET~
13 DS0 BR1 NC
14 WRITE BR2 AM5
15 GND BR3 A23
16 DTACK~ AM0 A22
17 GND AM1 A21
18 AS AM2 A20
19 GND AM3 A19
20 IACK GND A18
21 IACKIN SERCLK(1) A17
22 IACKOUT~ SERDAT~(1) A16
23 AM4 GND A15
24 A07 IRQ7 A14
25 A06 IRQ6 A13
26 A05 IRQ5~ A12
27 A04 IRQ4~ A11
28 A03 IRQ3~ A10
29 A02 IRQ2~ A09
30 A01 IRQ1~ A08
31 -12 V +5 VSTDBY +12 V
32 +5 V +5 V +5 V
